HomeCLEO C10-1R
The compact design helps conserve counter space with its small footprint, and because peripherals are integrated into the all-in-one, it keeps workspaces uncluttered.
SHARE
OVERVIEW
Not Just a Pretty Face
Packed with power, the Cleo C10-1R POS delivers top performance in a compact, minimalistic design, elevating the checkout experience in retail and hospitality.
High-Speed Data Processing
Built on the latest technology that supports new, more demanding applications and databases. The Rockchip RK3576 processor, eMMC 64GB memory ensure high-speed data processing and responsiveness in all situations.
Think Big, Act Small
The Cleo C10-1R is specially designed for counter-limited industries.
The compact design helps conserve counter space with its small footprint, and because peripherals are integrated into the all-in-one, it keeps workspaces uncluttered.
Android 15 & GMS
CLEO C10-1R now runs on Android 15 with Google Mobile Services (GMS), offering advanced security and privacy protection, refined device manageability, and seamless integration with the Google ecosystem for enhanced POS performance and long-term support.
Key Features
- Android 15 & Google GMS
- Compact all-in-one design
- 10.1" PCAP touch display
- Embedded 3" thermal printer and payment peripherals
- Rich I/O interface
- Concealed cables keep the counter clutter-free
Optional Features
- MSR, IC Card Reader, Fingerprint, RFID
- 2D Barcode Scanner
- 8MP Camera
- CD-101C, CoCo
- Wi-Fi, BT
Interested in Partner Tech Products?
| Item | C10-1R |
|---|---|
| Display | 10.1” , 9:16 , 800 x 1280 (250 nits) |
| Touch | PCAP touch |
| CPU | RK3576 Quad Cortex-A72 + quad Cortex-a53 up to 2.3 GHz |
| Memory | DDR4 4GB |
| Storage | eMMC 64GB |
| I/O Interface | 2 x serial ports, RS232 (RJ45), 0V/5V/12V selected in UI (COM1, COM2) (option) |
| 1 x LAN (IEEE 802.3 10/100/1000 Mbps) | |
| 1 x HDMI+ 1 x Type-C (data transfer only) | |
| 4 x USB 3.2 + 2 x USB 2.0 | |
| 1 x RJ11 port with support for 2 cash drawers with 24V / 12V jumper setting | |
| 1 x audio (1 x line-out) | |
| 1 x DC +24V input | |
| Printer | 3" Thermal Printer |
| Speaker | 1 x speaker 3W |
| Peripheral Options | MSR, EMV reader, Fingerprint reader, RFID / NFC reader, 2D barcode scanner, 8MP camera, USB 2nd display (CD-101, COCO) |
| Wireless Option | Wi-Fi6 : 2T2R 802.11 ax/ac/a/b/g/n Wi-Fi + BT 5.1 (on board) |
| Display Support | 2 independent displays (main display + CD-101C/COCO or HDMI) |
| Operating System | Android 15 GMS |
| TPM & vPro | N/A |
| Power Adaptor | AC-In 100~240V / DC-Out 24V,72W |
| Reliability | System operating temperature: 0~40°C / 32~104°F |
| System humidity: 15% ~ 80% | |
| Storage temperature: -20~60°C/ -4~140°F | |
| Dimensions (WxHxD) | 262.26 x 291.77 x 247.13 mm / 10.33 x 11.49 x 9.72 in |
| Weight | 3.3 Kg / 7.28 lb |
