CLEO C14-1E

All-in-one POS terminal with a 14.1-inch touch display, packed with power in a compact and modern form factor. It provides an excellent value – no matter if you operate a cafe or a large retail or restaurant chain.

Request More Info

OVERVIEW

SPECIFICATIONS

Same Base. Different Screen Size.

Cleo C14 is a plug-and-play, all-in-one POS terminal with a 14.1-inch PCAP touch display and an integrated receipt printer. The compact and sleek design makes this an ideal POS solution in stores and cafes with limited counter space.

Second Customer-Facing Display

Bring customer interaction to the next level and enable customers to keep track of their purchases with a second customer-facing display. C14 supports use of a 10.1″ second display with a special mounting kit that elegantly attach it to the back of the terminal. The Elkhart Lake version of the terminal allows for a third display such as a digital to be connected via the HDMI port.

Safely Integrated Peripherals

Cleo comes with an integrated lockable 3-inch thermal printer and Partner Tech offers several optional peripherals that allows you to customize it for your needs.A broad selection of interface options ensures you can easily connect all your POS peripherals.

Choose between the following peripherals:

2D barcode scanner
5MP camera
Finger print reader
NFC reader
MSR
EMV reader
10.1-inch customer-facing display

Power & Speed

Powered by an Intel Elkhart Lake processor and equipped with a M.2 PCle solid-state drive and DDR4 RAM memory, Cleo can handle most of the most demanding applications and databases.

Key Features

Compact all-in-one design
Available with 14.1″ PCAP touch display
Intel Elkhart Lake processor
High speed M.2 SSD for maximum performance and reliability
Up to 16 GB DDR4 RAM

Optional Features

Available for Windows 10, Windows 11, and Ubuntu
MSR, EMV reader, finger print reader and NFC reader
5MP camera and 2D barcode scanner
10.1″ customer display (CD-101C)
Optional Wi-Fi and BT connectivity

Interested in Partner Tech Products?

Contact Now

Item	C14-1E (Elkhart Lake)
Size	14.1″
Aspect Ratio	16:9
Resolution	1366 x 768
Brightness (typical)	220 nits
Touch	PCAP touch
CPU	Intel® Celeron® Processor J6412 (Elkhart Lake)
Memory	DDR4 4GB, 8GB, 16GB
Storage	M.2 PCIe SSD: 128G / 256G / 512G
External I/O Interfaces	4 x USB 3.2 + 2 x USB 2.0
	4 x Serial ports, RS232 (RJ45), 0V/5V/12V selected in BIOS (COM1, COM2, COM3, COM4)
	1 x LAN (IEEE 802.3 10/100/1000 Mbps Ethernet, RJ45)
	1 x RJ11 port with support for 2 cash drawers with 24V / 12V jumper setting
	1 x Audio (1 x line out)
	1 x HDMI 2.1
	1 x DC +24V input
Speaker	1 x speaker (3W)
Printer	3" thermal printer
Peripherals (optional)	MSR, EMV Reader, finger print reader, NFC reader
	2D barcode scanner
	5MP camera
	Customer-facing display (CD-101C)
Wi-Fi/ BT (optional)	Wi-Fi 6E Intel AX210 IEEE 802.11 a/b/g/n/acR2/axR2, BT5.2
Display Support	3 Independent Displays (Main Display + HDMI + CD-101C )
Operating System	Windows 11 IoT Enterprise GAC (64bit)
	Windows 10 IoT Enterprise LTSC 21H2 (64bit) and newer version
	Ubuntu 22.04
TPM	H/W TPM 2.0
Power Adaptor	AC-In 100~240V / DC-Out 24V,72W
Reliability	System Operating Temperature: 0~104°F/ 0~40°C
	System Humidity: 15% ~ 80%
	Storage Temperature: -4~140°F/ -20~60°C
Dimensions	13.41″ (W) x 12.41″ (H) x 9.73″ (D) / 341 mm (W) x 315 mm (H) x 247.13 mm (D)
Weight	8.82 Ibs / 4 kg

Download datasheet
