Thermal Receipt Printer

RP-630 is the most solid and powerful thermal receipt printer for retail and hospitality environment.


未命名設計 (37)

High Performance Thermal Printer

RP-630 is a robust and powerful thermal receipt printer for use in retail and hospitality environments. Its offers high-speed printing with multiple interface options.

未命名設計 (38)

Maximum Protection

Maximum protection against dust and splashes of water and other liquids can be applied with an optional water spill-proof cover and power adaptor cover – a critical protection in restaurants, bars, commercial kitchens, etc. RP-630 is Energy Star-certified, which means the printer is both power efficient and environmental-friendly.

Interested in Learning More about Partner Tech Products?

Contact us now and we'll be in touch shortly.
Item RP-630
Printing Method direct thermal
Paper Loading top
Speed 250mm/sec
Width 80 mm
Resolution 203 dpi x 180 dpi
Paper Type thermal paper
Width 57.5mm / 80mm
Thickness 0.06mm~0.08mm
Roll Diameter max. 83mm
Roll Core Inner 12.5mm  ± 0.5mm
Memory   RAM: 2MB, Flash: 4MB
Reliability TPH life 150km
MCBF 60,000,000 lines
Auto cutter   1,500,000 cuts
Sensor Paper End, Cover Open, Black Mark
Interface USB+Serial + Ethernet
Emulation ESC/POS command compatible
Driver Window, MAC LinuxCUPS, OPOS, JavaPOS
Power Type External adaptor
AC 100~240Vac 50/60 Hz
DC 24 Vdc / 2.15A
Temperature Operation: 41°F ~ 113F°
Storage: -40 °F ~ 140°F
Dimension 7.87in x 5.71in x 5.71in (L x W x H)
Weight 3.20 lb / 1.45 kg
Color Black
Certificate FCC, CE, CB, 3C, Energy Star, VCCI



Sleek and compact thermal printer with front loading.
