HomeAudrey A5 II
All-in-one Touch Screen POS Terminal
Audrey II, based on our most loved POS terminal, but equipped with more processing power, updated looks, ultra-slim bezel, optically bonded touchscreen, Windows 11, and more.
SHARE
OVERVIEW
-
Better, Brighter Display
A slimmer (7 mm) bezel and optical bonding results in a brighter display. -
More Power
Cutting-edge speed with Windows 11 and Intel 11 Gen Tiger Lake CPU. -
POS Ready
Customizable with peripherals and large selection of interfaces.
Sleek Design with Ultra-slim Bezel
Based on Audrey's elegant design, but with a significantly slimmer bezel (only 7 mm), Audrey II looks even more appealing than its predecessor and matches any type of modern store interior. All cables are neatly concealed inside the base to keep the counter clutter free.
Brighter Display with Optical Bonding and Anti-Glare Glass
Audrey II is available with a full HD 15.6-inch on-cell touch display. The screen technology has been further improved and has an optically bonded display, which results in a significantly brighter display and better touch precision. Anti-glare glass provides a better image, causing less strain on the eyes. Audrey II supports a total of three displays, including the main display and customer display and digital signage via the HDMI port.
Blazing Speed & Performance
Powered by Intel®'s 11th generation high-performance processor, Audrey II delivers powerful performance for more diversified applications and databases, including AI and computer vision applications. The Tiger Lake processor combined with a M.2 PCIe solid-state drive and up to 32 GB DDR4 RAM memory ensures that Audrey II has the capacity to run the most data intensive POS applications for many years to come.
Built for POS with Many Interfaces
Audrey II offers even more interface options than the previous generation, including support for the more powerful Type-C USB connector. All connectors are protected by a cover to shield the computer from dust and dirt. Audrey II is also available with the EX-300 expansion I/O box that further expands the connectivity options and the ability communicate with more peripherals.
Customize With Peripherals
Audrey II comes with a large selection of peripherals that allows you to configure your POS terminal with different payment terminal brackets, finger print reader, EMV reader, MSR, camera, cash drawer, NFC/RFID-reader, customer display, extra digital display, printer, and barcode reader.
Customer Displays for All Your Needs
Flexible Mounting Solutions
The silver tabletop A-base comes as standard, but there are also other mounting solutions available, including the foldable T-base and other mounts with support for standard VESA, including wall mounts and pole mounts with the option of landscape or portrait mode.
Built to Last
The durable and fanless design protects the unit from dust and debris and makes it more resistant to shocks and vibrations while providing a completely silent operation. The unit is spill proof to meet the demands in restaurants and other environments where spills easily happen. On top of all this, Audrey II is backed by a 5-year warranty.
Key Features
- Extra bright (optically bonded) 15.6" FHD display with anti-glare
- Ultra thin (7 mm) bezel
- Intel's 11th generation "Tiger Lake" processor
- High speed M.2 PCIe solid drive
- Up to 32 GB DDR4 RAM
- 5-year warranty
Optional Features
- Windows 11 IoT Enterprise GAC (64bit)
Windows 10 IoT Enterprise (64bit)
Linux (Ubuntu) - PS-103 printer stand with powered USB hub
- MSR, EMV reader, fingerprint reader and RFID reader
- Customer facing displays (VFD, 10.1", 11.6", 15.6")
- Wi-Fi (including 6E) and BT connectivity
- Several different mounting solutions
Interested in Learning More about Partner Tech Products?
Contact us now and we'll be in touch shortly.
| Item | A5-2-T (Tiger Lake) |
| Size | 15.6" |
| Aspect Ratio | 16:9 |
| Resolution | 1920 x 1080 |
| Brightness (typical) | 400 nits |
| Touch | Optically Bonded, On-cell Touch Display Ultra-thin 7 mm Bezel, with Anti-Glare |
| CPU |
Intel® Celeron® 6305 (Tiger Lake UP3), Intel® Core™ i3-1115G4 (Tiger Lake UP3) Intel® Core™ i5-1145G7, Vpro (Tiger Lake UP3 ) Intel® Core™ i7-1185G7, Vpro (Tiger Lake UP3 ) |
| Memory | DDR4 4GB, 8GB, 16GB, 32GB |
| Storage | M.2 PCIe SSD: 128G / 256G / 512G |
| External I/O Interface | 2 x Serial Ports, RS232 (RJ45), 0V/5V/12V selected in BIOS (COM1, COM2) |
| 1 x Intel LAN (IEEE 802.3 10/100/1000 Mbps Ethernet, RJ45) | |
| 1 x RJ11 port with support for 2 cash drawers with 24V / 12V jumper setting | |
| 1 x DC+ 12V output | |
| 4 x USB 3.2 + 2 x USB 2.0 | |
| 1 x DC +12V input | |
| 1 x Audio (1 x line-out) | |
| 1 x HDMI | |
| 1 x Type-C (USB 3.1 Gen 1, 5Gbps) | |
| Speaker | 1 x Speaker (3W) |
| Peripheral Options | MSR, EMV Reader, Fingerprint Reader, 5MP Camera, 2D Barcode Scanner, Receipt Printer, EX-300 IO Expansion Box, Printer Stand, Customer Displays |
| Optional Wi-Fi+BT | Wi-Fi 6E Intel AX210 |
| IEEE 802.11 a/b/g/n/acR2/axR2, BT5.2 | |
| Display Support | 3 Independent Displays (Main Display + HDMI + Type C) |
| Spill & Dust Resistant | IP54 Certified |
| Operation System | 1. Windows 11 IoT Enterprise GAC (64bit) |
| 2. Windows 10 IoT Enterprise (64bit) | |
| 3. Linux (Ubuntu) | |
| Software | 1. Intel V-Pro (i5/i7 CPU only) |
| 2. S/W TPM 2.0 (BIOS) | |
| Power Adaptor | AC-In 100~240V / DC-Out 12V, 65W / 90W |
| Reliability | System Operating Temperature: 0~40°C/ 32~104°F |
| System Humidity: 15% ~ 80% | |
| Storage Temperature: -20~60°C/ -4~140°F | |
| Dimensions (Wx Hx D) | 364 x 288 x 201 mm / 14.33 x 11.34 x 7.91 inch |
| Weight | 5.4 kgs / 11.9 Ibs |
