CLEO C10-1E POS (Windows)

Compact All-in-one Touch Screen POS Terminal

Space-saving and elegant 10.1" POS terminal. Complete with a built-in printer, interactive customer display and support for all your preferred payment options. Available for Windows and Linux Ubuntu.

SHARE

5


Same Base. Different Screen Size.

Cleo C10/C14 is a space-saving, all-in-one POS terminal with a smartly designed base that supports a 10.1 or 14.1-inch PCAP touch display. The compact and sleek design makes this an ideal POS solution for seasonal event, small stores, cafés, bars, food trucks, and other places where counter space is precious.

6


Second Customer-Facing Display

Bring customer interaction to the next level and allow customers to keep track of their purchases with a second customer-facing display that elegantly attaches to the back of the terminal and keeps all cables concealed inside the base.

The Elkhart Lake version of Cleo supports a third display, which allows a digital signage to be connected via the HDMI port.

7


Save Space with Built-in Printer

Cleo C10/C14 comes with an fully integrated and lockable 3-inch thermal printer that saves counter space and helps keep the clutter and cables to a minimal.

6


All Your Preferred Payment Types

With an optional built-in MSR, EMV reader and NFC reader, Cleo C10/C14 can support all your preferred payment types, including contactless and mobile payments. If preferred, Cleo can instead be combined with a separate payment terminal from any of the leading brands.
7

Faster Throughput with Barcode Scanning

Increase throughput at the checkout with a 2D barcode scanner for reading of regular barcodes and coupons with QR codes. The barcode scanner can be attached to either side of the display. In addition, Cleo can be equipped with a camera for item and facial recognition and there is also an option to have an integrated fingerprint reader.
6

Top of the Line Power and Speed

Powered by an Intel Elkhart Lake or Rockchip RK3568 processor and equipped with a M.2 PCle solid-state drive and DDR4 RAM memory, Cleo C10/C14 can handle the most demanding applications without slowing down.

Cleo C10/C14 is available for Windows 10/11, Android 12 and Linux Ubuntu 22.04.
7

Built to Last

The durable construction with a fanless solid-state drive protects the POS terminal from dust and makes it more resistant to shocks and vibrations.

In addition, Cleo C10/C14 is protected by a up to 3-year warranty (Windows).

Key Features


  • Compact all-in-one design
  • Available with 10.1″ and 14.1" PCAP touch display
  • Choose between the Intel Elkhart Lake or Rockchip processor
  • High speed M.2 SSD for maximum performance and reliability
  • Up to 16 GB DDR4 RAM
  • 3-year warranty (Windows)

Optional Features

  • Available for Windows 10/11, Android 12 and Linux Ubuntu 22.04
  • MSR, EMV reader, fingerprint reader and NFC reader
  • 5MP camera and 2D barcode scanner
  • 10.1″ customer display (CD-101C), 3rd display (Elkhart Lake)
  • Optional Wi-Fi and BT connectivity


Interested in Learning More about Partner Tech Products?

Contact us now and we'll be in touch shortly.
Item​ C10-1E (Elkhart Lake)
Size 10.1”
Aspect Ratio 16:9
Resolution 800 x 1280
Brightness (typical) 250 nits
Touch​ PCAP touch​
CPU Intel® Celeron® Processor J6412 (Elkhart Lake)
Memory​ DDR4 4GB, 8GB, 16GB
Storage​ M.2 PCIe SSD: 128GB / 256GB​ / 512GB
I/O Interfaces​ 4 x USB 3.2 + 2 x USB 2.0​
4 x Serial ports, RS-232 (RJ45), 0V/5V/12V selected in BIOS (COM1, COM2, COM3, COM4)
1 x LAN (IEEE 802.3 10/100/1000 Mbps Ethernet, RJ45)​
1 x RJ11 port with support for 2 cash drawers with 24V / 12V jumper setting​
1 x audio (1 x line out)​
1 x HDMI​ 2.1
1 x DC + 24V input​
Speaker​ 1 x speaker (3W)​
Printer 3" thermal printer
Peripheral​s Options MSR, EMV reader, fingerprint reader, RFID/NFC reader
2D barcode scanner
5MP camera​
Customer-facing display (CD-101C)
Wi-Fi/ BT ​(option)​ Wi-Fi 6E Intel AX210 IEEE 802.11 a/b/g/n/acR2/axR2
BT5.2
Display Support​ 3 independent displays (main display + HDMI + CD-101C )​
Operating Systems Windows 11 IoT Enterprise GAC (64bit)
Windows 10 IoT Enterprise LTSC 21H2 (64bit)​ and newer version
Linux Ubuntu 22.04
TPM H/W TPM 2.0
Power Adaptor​ AC-In 100~240V / DC-Out 24V,72W
Reliability​ System operating temperature: 0~104°F/ 0~40°C
System humidity: 15% ~ 80%​
Storage temperature: -4~140°F/ -20~60°C
Dimensions​ 10.33" (W) x 11.49" (H) x 9.72" (D) / 262.26 mm​ (W) x 291.77 mm​ (H) x 247.13 mm​ (D)
Weight​ 7.28 lb /3.3 kg
